Remote ACP detailing
From façade drawings
to your CNC workflow.
Aluminium composite panel layouts, fabrication drawings and unfolded DXF files. Detailed by FFE. Manufactured in your own workshop.
See the three steps ↓
Step 01
You send the drawings.
Share your façade plans and elevations, confirmed dimensions, panel material and thickness, plus the required joints, folds and fixing details.
We review your requirements and agree on the scope before detailing begins.
Step 02
We detail every panel.
FFE develops the panel division, numbering and colour layout, with corner, opening and folding details based on your project requirements.
You review the layout and fabrication details before the final DXF package is prepared.
Step 03
You receive the DXF package.
Receive unfolded panel DXF files with separate cutting and grooving layers, PDF drawings and a panel schedule, according to the agreed scope.
Your workshop prepares the CAM toolpaths and machine settings, then fabricates the panels locally.
A clear handover
One organised fabrication package.
Panel layouts and details for review.
Unfolded geometry with separate cut and groove layers.
Panel references and quantities aligned with the drawings.
Deliverables are agreed for each project. Final dimensions, material and fixing details must be confirmed before fabrication. Your CNC operator sets tools, machining depths and toolpaths in CAM.
Send us your drawings and requirements.
Contact FFE to confirm your scope, timing and quotation.
